OBD II Scanner Code Reader


Pro-series OBD II scanner works on OBD II compliant cars that were made between 1996 and 2004


This auto scanner (OBD II car reader) will quickly find your trouble issues by reading the specific diagnostic trouble code (DTC) from the car’s computer and displaying it to you and shows its description as well. Moreover, this tool is able to display live data from your car’s computer, such as current RPM, engine coolant temperature, vehicle speed, oxygen sensor data, and much more. This is the latest model which enables its user to update it via the internet from the manufacturer’s website for free.

Additional Information

Compatible VehiclesThis item is compatible with OBD II compliant cars and light trucks 1996 – 2004 .
Compatible OBD II ProtocolsSAE J1850 – PWM, SAE J1850 – VPW, ISO 9141-2, ISO 14230-4 – KWP 2000
Product Features
  • Works with cars & trucks that are OBD II compliant 1996 – 2004: (including the VPW, PWM, ISO and KWP 2000
  • Reads and clears generic and manufacturer specific Diagnostic Trouble Codes (DTC)
  • Updatable via the Internet, using RS-232 serial port.
  • Turns off check engine light
  • Trouble codes and code description is shown on the LCD display. No code book is needed.
  • Displays live data:
    • Fuel SYS1 – Fuel System Status
    • Fuel SYS2 – Fuel System Status
    • Coolant temp – Coolant Temperature
    • ST FTRM1 – Short Term Fuel Trim
    • LT FTRM1 – Long Term Fuel Trim
    • ST FTRM2 – Short Term Fuel Trim
    • LT FTRM2 – Long Term Fuel Trim
    • Engine RPM
    • Veh Speed – Vehicle Speed
    • IAT – Intake Air Temperature
    • Abslt TPS(%) – Absolute Throttle Position
    • Second Air
    • O2S12 – Oxygen sensor value
    • O2S22 – Oxygen sensor value
  • Supports multiple trouble code requests: generic codes, pending codes and manufacturer’s specific codes
  • Reads Freeze Frame Data
  • Tests I/M Reading Status
  • Reads vehicle information including VIN# (if your vehicle is able to provide that)
  • Rescans Data
  • Easy to use with one plug-in
  • Highly reliable and accurate
  • Easy-to-read crystal-clear backlit LCD display
  • Stand-alone unit with no need for an additional laptop computer to operate
  • Performs continuous DTC scan
  • Safely communicates with the on-board computer
